| مكان المنشأ: | تشنغدو الصين |
|---|---|
| اسم العلامة التجارية: | HLLP |
| رقم الموديل: | DN1102 |
| الحد الأدنى لكمية: | 100 مجموعة |
| الأسعار: | US$ 0.4-5 per set |
| تفاصيل التغليف: | منصات الكرتون أو الحالات الخشبية أو حسب الاقتضاء |
| وقت التسليم: | 10-20 أيام |
| شروط الدفع: | ر/ر |
| القدرة على العرض: | 100000 مجموعة في الشهر |
| نوع المنتج: | طقم مسدود | أداء طويل الأمد: | 50+ سنة خدمة الخدمة |
|---|---|---|---|
| تطبيق: | لموصلات ACSR و AAC و AAAC و OPGW | تثبيت: | خالية من الأدوات ، تثبيت يدوي |
| ميزة رئيسية: | التخميد المتفوق في الاهتزاز والتعب | جودة مضمونة: | يحقق 100 ٪ RBS (قوة كسر مصنفة) |
| تطبيق عالمي: | يناسب ACSR ، AAAC ، ADSS |
Key Features:
High Tensile Strength: Constructed from premium materials to withstand extreme mechanical loads.
Corrosion Resistance: Galvanized or aluminum alloy options offer long-lasting protection against harsh weather and corrosive environments.
Easy Installation: Preformed design allows for quick, tool-free installation, reducing labor time and costs.
Versatile Compatibility: Suitable for ACSR, AAC, AAAC, and other common cable types.
Enhanced Safety: Eliminates the need for splices or clamps, minimizing potential failure points.
| Parameter / Specification | Model PD-ACSR1 | Model PD-ACSR2 | Model PD-AAAC1 | Model PD-ADSS1 | Notes |
|---|---|---|---|---|---|
| Applicable Cable Type | ACSR | ACSR | AAC/AAAC | ADSS & OPGW | - |
| Cable Diameter Range (mm) | 10.0 - 14.0 | 14.1 - 18.0 | 8.0 - 12.0 | 10.0 - 16.0 | Custom sizes available |
| Ultimate Breaking Load (kN) | ≥ 30 | ≥ 50 | ≥ 20 | ≥ 25 | Meets IEC 61284 standards |
| Weight (kg per unit) | 0.45 | 0.75 | 0.35 | 0.50 | ± 0.05 kg |
| Material | Galvanized Steel Wire | Galvanized Steel Wire | Aluminum Alloy | Aluminum Alloy | Highly corrosion-resistant |
| Galvanization Type | Class A / Special | Class A / Special | - | - | Upon request |
| Operating Temperature | -40°C to +80°C | -40°C to +80°C | -40°C to +80°C | -40°C to +80°C | |
| Standard Compliance | IEC 61284, ASTM | IEC 61284, ASTM | IEC 61284, ASTM | IEC 61284, ASTM | Customizable to other standards |
Applications:
Overhead power transmission and distribution lines.
Telecommunication and fiber optic cable support.
Railway electrification systems.
Renewable energy projects (e.g., wind and solar farms).
Trust our Preformed Dead End for a maintenance-free, secure cable termination that meets international standards. Boost your project’s efficiency and safety with our proven solution!
Our customization options include:
Material Specification: Choose from various materials like galvanized steel, aluminum alloy, or special coatings for enhanced corrosion resistance.
Precise Sizing: Get exact sizes tailored to your cable's diameter and tensile strength needs.
Special Packaging: Request specific packaging (e.g., master cartons, palletization) for easier logistics and on-site handling.
Branding & Marking: Add your company logo, product IDs, or QR codes for traceability and brand consistency.
Tell us your needs, and we'll engineer the solution.
